pupilio is a lightweight Python SDK for the Pupil.IO eye-trackers developed by Hangzhou Shenning Technology Co., Ltd. It offers a user-friendly interface that covers core eye-tracking functions like data recording, calibration, validation, and real-time access to gaze data. "pupilio" seamlessly integrates with popular platforms such as PsychoPy and PyGame, it enables quick development of eye-tracking studies.
Pupil.IO is a high-speed, high-precision eye-tracking system featuring an all-in-one (AIO) plug-and-play design that is ideal for both scientific research and clinical applications. With minimal setup (just power on and start tracking), it delivers lab-grade accuracy in a compact, user-friendly form factor.
- Precision Tracking: Capture high-frequency eye movement and pupil dynamics with lab-grade accuracy.
- Seamless Compatibility: Native integration with PsychoPy, PyGame, and other Python experimental platforms.
- Intuitive Workflow: Simplified calibration, validation, and recording with minimal setup.
| Attribute | Specification |
|---|---|
| Sample Rate | 200 Hz |
| Accuracy | 0.5-1° |
| Precision | 0.03° |
| Blink/Occlusion Recovery | 5 ms @ 200 Hz |
| Head Box | 40 cm x 40 cm @ 70 cm |
| Operation Range | 50 - 90 cm |
| Gaze Signal Delay | < 25 ms |
| Tracking Technology | Neural Networks |
| Dimension | 32 cm x 45 cm x 20 cm |
| Weight | 5 kg [Eye-tracker + Display + Compute Module] |
| Operating System | Windows 11 |
| SDK | C/C++/Python/Matlab |
Currently, all eye trackers shipped with Pupilio are pre-configured with the necessary Pupilio Python packages. If we need to upgrade this package, please enter the following command in the command prompt or PowerShell window:
pip install -U pupilioHere is a simple example to get started with Pupilio:
# load PyGame library
import pygame
from pygame.locals import FULLSCREEN, HWSURFACE
# initialize PyGame
pygame.init()
# define the scree size
scn_width, scn_height = (1920, 1080)
# set a fullscreen mode with the above size
win = pygame.display.set_mode((scn_width, scn_height), FULLSCREEN|HWSURFACE)
# load Pupilio library
from pupilio import Pupilio
# instantiate a connection to the tracker
pupil_io = Pupilio()
# create a task session, and set a session name.
# The session name must contain only letters, digits or underscores without any special characters.
pupil_io.create_session(session_name="quick_start")
# calibration and validation (recommended)
# set 'validate' to True if we would like to verify the calibration results
pupil_io.calibration_draw(screen=win, validate=True)
# start retrieving gaze
pupil_io.start_sampling()
# hang the main thread for 5 seconds by game
# eye tracking sampling are running on the background thread
pygame.time.wait(5 * 1000)
# stop eye tracking sampling
pupil_io.stop_sampling()
# sleep for 100 ms to capture ending samples
pygame.time.wait(100)
# save eye movement data
pupil_io.save_data("eye_movement.csv")
# release the tracker instance
# clean up Pupilio resources
pupil_io.release()
# quit pygame
pygame.quit()Detect fixations and saccades using the I-DT (Identification by Dispersion Threshold) algorithm. The I-DT algorithm identifies fixations as groups of consecutive samples where the dispersion (sum of x and y ranges) remains below a specified threshold for a minimum duration.
Example:
import glob
import os
from pupilio import EventDetection
ed = EventDetection()
out_dir = 'output'
os.makedirs(out_dir, exist_ok=True)
f = open('error.txt', 'w')
for i in glob.glob(r'example.csv'):
try:
ed.detect(i, output_dir=out_dir, which_eye='right')
except Exception as e:
f.write(i + ',' + str(e) + '\n')
f.flush()Comprehensive documentation is available at Pupilio Documentation.
If you encounter any issues or have questions, please open an issue on GitHub or contact zhugc2016@gmail.com.
Pupilio is a proprietary software developed by Hangzhou Shenning Technology Co., Ltd. All rights reserved. Unauthorized use, distribution, or modification is prohibited without explicit permission. For licensing inquiries, please contact zhugc2016@gmail.com.
Pupilio is developed and maintained by Hangzhou Shenning Technology Co., Ltd. Special thanks to the community for their valuable feedback and support.
