Hand classifier

This repo contains how we develop a 5-layer convolutional neural network in PyTorch. The code works with CPU and GPU.

Our approaches

Our CNN architecture is based on the R-Net in MTCNN[1].

Our dataset is based on EPIC-KITCHENS-100 [2], an egocentric video dataset. In the image below are four examples from our dataset, where c0, c1 mean left_hand, right_hand.

We also apply PyTorch transforms to enable Data Augmentation in training. The transforms we utilise are as follows. Kind reminder: Do NOT enable flip in the training due to the reflectional symmetry.

transforms.RandomCrop(20),
transforms.RandomAffine(degrees=(30),translate=(0.1, 0.2)),
transforms.Resize(28)

Requirements

Python 3.7 or later with all requirements.txt dependencies installed, including torch >= 1.6. To install run:

$ pip install -U -r requirements.txt

Tutorials

• Google Colab Notebook

$ python .\hand_cnn.py -h
usage: hand_cnn.py [-h] [--mode MODE] [--dataset DATASET]
                   [--save-txt SAVE_TXT] [--batch-size BATCH_SIZE]
                   [--epochs EPOCHS] [--lr LR] [--augment] [--weight WEIGHT]
                   [--source SOURCE]

Training

optional arguments:
  -h, --help            show this help message and exit
  --mode MODE           Runing mode: train, test, detect
  --dataset DATASET     Path to dataset
  --save-txt SAVE_TXT   Path to results
  --batch-size BATCH_SIZE
  --epochs EPOCHS
  --lr LR               Learning rate
  --augment             Data augmentation
  --weight WEIGHT       Weight file to load.

Training command example command.

python hand_cnn.py --mode train --dataset datasets/handcrops --save-txt results --batch-size 100 --epochs 3 --lr 0.0001 --augment

Resuming training example command. We require to set the number of epochs a larger value than one saved in the checkpoint.

python hand_cnn.py --mode train --dataset datasets/handcrops --weight weights/handcnn.pt --save-txt results --batch-size 100 --epochs 10 --lr 0.0001 --augment

Plot training process command:

from utils import plot_process
plot_process('results')

Evaluation

optional arguments:
  -h, --help            show this help message and exit
  --mode MODE           Runing mode: train, test, detect
  --dataset DATASET     Path to dataset
  --save-txt SAVE_TXT   Path to results
  --batch-size BATCH_SIZE
  --epochs EPOCHS
  --lr LR               Learning rate
  --augment             Data augmentation
  --weight WEIGHT       Weight file to load.
  --source SOURCE       Source images for detection.

Evaluation on test set example with trained weight example command.

python hand_cnn.py --mode test --batch-size 100 --weight weights/handcnn.pt

Detection

optional arguments:
  -h, --help            show this help message and exit
  --mode MODE           Runing mode: train, test, detect
  --dataset DATASET     Path to dataset
  --save-txt SAVE_TXT   Path to results
  --batch-size BATCH_SIZE
  --epochs EPOCHS
  --lr LR               Learning rate
  --augment             Data augmentation
  --weight WEIGHT       Weight file to load.
  --source SOURCE       Source images for detection.

Detection of samples example command:

python hand_cnn.py --mode detect --weight weights/handcnn.pt --source samples

Easy integration

Our implementation should be easy to be integrated into your codes.

model = HandCropCNN()
device = torch.device("cuda:0" if torch.cuda.is_available() else "cpu")
model.to(device)
weight_file = 'weights/handcnn.pt'

patches = []
imgs = sorted(glob.glob('samples/' + '*jpg'))
for im_path in imgs:
    img = cv2.imread(im_path)
    img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
    patches.append(img)
patches = tuple(patches)

with open('datasets/handcrops/classes.names', 'r') as f:
    classes = [line.rstrip() for line in f]

cls_conf, labels = model.detect(device, weight_file, patches, classes)

References

1. Zhang, K. et al. (2016) ‘Joint Face Detection and Alignment Using Multitask Cascaded Convolutional Networks’, IEEE Signal Processing Letters. Institute of Electrical and Electronics Engineers Inc., 23(10), pp. 1499–1503. doi: 10.1109/LSP.2016.2603342.
2. Damen, D. et al. (2020) ‘The EPIC-KITCHENS Dataset: Collection, Challenges and Baselines’, IEEE Transactions on Pattern Analysis and Machine Intelligence. Institute of Electrical and Electronics Engineers (IEEE), pp. 1–1. Available at: http://arxiv.org/abs/2005.00343 (Accessed: 16 August 2020).
