RGB-led-cube

This project was created to learn more about circuit boards, electronic components, 3D printing, electricity and embedded programming. It consists of 4x4x4 RGB LEDs, each able to be turned on individually using only 6 Arduino pins by using Shift Registers and Bit Angle Modulation.

Demos:

sparkles.mov

fireworks-trim2.mp4

Dev Notes: Pitch Slides

A project inspired by Kevin Darrah on YouTube && Malt Whiskey on YouTube
