This pipeline was developed in close collaboration with clinicians, computational biologists, laboratory scientists and mathematicians to comprehensively analyse spatial proteomics data. SpOOx automates the processing of MCD image files (generated by the Fluidigm Hyperion Imaging System) using imctools for image processing, DeepCell for segmentation, and custom scripts to extract marker intensities, perform quality control and cell clustering to aid cell phenotyping. SpOOx also includes procedures for novel spatial statistical analysis. We recommend uploading the outputs of SpOOx to our comprehensive analytics and visualisation platform MDV Multi-Dimensional View.
The SpOOx pipeline has been tested on CENTOS and compatible OS on an HPC Linux cluster. To run the pipeline effectively, a minimum of 16GB of RAM is required. In terms of disk space, the SpOOx code is small (20MB). The size of the projects can get quite large depending on number of MCD or OME-TIFF files analsyed. For example, the demo data set used in the tutorial (see below) which contains two MCD files containing five regions of interest and their metadata takes up ~800MB of disk space once analysed.
The following notes assume that conda has been installed and in the system path - guidance on setting up conda in a Linux environment can be found here. The SpOOx pipeline uses the Ruffus framework (Goodstadt, L. "Ruffus: a lightweight Python library for computational pipelines" Bioinformatics, Volume 26, Issue 21, November 2010, Pages 2778–2779, https://doi.org/10.1093/bioinformatics/btq524). Please refer to Ruffus documentation for specific pipeline queries.
A zipped version of the SpOOx code can be downloaded, or the repository can be cloned using:
git clone https://github.com/bioinfbloke/SpOOx.git
The conda environment is created using:
conda activate base
conda env create -n hyperion -f </path/to/>hyperion.yml
conda activate hyperion
conda can be slow amd take up large amounts of memory when installing the python environment, hence we recommend using mamba thus:
conda activate base
conda install mamba -n base -c conda-forge
mamba env create -n hyperion -f </path/to/>hyperion.yml
conda activate hyperion
Sample data containing two (relatively) small .mcd files (total zipped size ~ 800Mb) can be found here:
https://zenodo.org/record/6513508/files/sample_data.tar.gz
There is a tutorial showing how to process an example data set (total size when complete 800MB).
Parameters are specified in the pipeline.yaml file in the working directory
For example you will see:
deepcell_options: --contrast 5
If you change the contrast option this will change it for every job that is run the pipeline.
If the pipeline is not run with the --local option, then it will attempt to submit jobs to the systems cluster mechanism, which needs to be specified in the cluster parameters, the following example is for slurm and a queue named 'batch'
cluster:
queue_manager: slurm
queue: batch
In local mode, To limit the number of jobs run at the same time use --multprocess X, where X specifies the number of concurrent jobs. This may be necessary if you are processing many mcd files as most steps process each ROI in parallel
python SpOOx/hyperion_pipeline.py make <target> --local --multiprocess 4
--multiprocess is probably not required when --local is not specified, as the queue manager will hopefully limit the amount of jobs run at one time according to current resources
The pipeline needs to know the path to the src directory of the pipeline, which is specified in scripts_dir. Paths can either be absolute or relative to where the pipeline is being run. Hence if the pipeline was installed in /home/user1/SpOOx and being run from the user1 directory ,either of the following would work:-
scripts_dir: /home/user1/SpOOx/src
scripts_dir: SpOOx/src
marker_file specifies the path to the marker file (see below). Again the path can be relative to the current working directory or absolute. The command hyperion_pipeline.py make make_config will generate a dummy marker file (to be filled in by the user)
marker_file: markers_panel.tsv
The pipeline needs to know which nucleus and cytoplasm markers are to be used in the segmentation step . This is a simple tab delimited text file with 4 columns:-
- marker_name the name of the marker
- nucleus whether this is a nucleus marker
- cytoplasm whether this is a cytoplasm marker (1 or 0)
- clustering whether to use this marker in the clustering step e.g.
marker_name nucleus cytoplasm clustering
DNA1 1 0 0
RAGE 0 1 1
CD56 0 0 1
..... .. .. ..
This file can be generated by the hyperion_pipeline.py make make_config step of the pipeline, which extracts the name of all markers from the mcd filed. This then has to be filled in manually with the appropriate values to show which markers are to be used for segmentation (nucleus/cytoplasm) and clustering.
Whether the file is generated by the pipeline or an existing file with the correct markers is used, the path of the file must be specified in pipeline.yml
marker_file: markers_panel.tsv
Config:
cd <your_working_dir>
cp pipeline.yml .
# edit pipeline.yml params (eg, cluster queue name; zegami options)
Input data - create a 'mcd' dir to contain all the .mcd data files to be analysed:
mkdir mcd
Copy (or symlink) .mcd files to mcd/ dir.
Each .mcd file should be in its own, named dir within the mcd dir. SpOOx and MDV relies on a specific naming scheme to process and parse files during the analysis. The file and dir names are constructed using three elements (<condition>, "SAMPLE", <sampleId>) separated by underscores. For example if your working directory was called test and you had two mcd files named COVID_SAMPLE_6 and HC_SAMPLE_1:
test/mcd/COVID_SAMPLE_6/COVID_SAMPLE_6.mcd
test/mcd/HC_SAMPLE_1/HC_SAMPLE_1.mcd
Subsequently, each region of interest (ROI) will have files named using this scheme:
<condition>, "SAMPLE", <sampleId>, "ROI", <roi_id>
For example:
COVID_SAMPLE_1_ROI_3.tiff
Similarly, in each row in the output data table will get a unique id:
<condition>, "SAMPLE", <sampleId>, "ROI", <roi_id>, "CELL", <cell_id>
For example:
COVID_SAMPLE_1_ROI_3_CELL_1.tiff
It is recommended you run the pipeline step by step (see below), when running for the first time to understand the process or for trouble shooting. The SpOOx pipeline can be run at any step and all steps upstream will be attempted. For example, you may wish to exclude certain ROIs because the staining was not optimal or the region captured was too small. In this case you could run up to the generation of ROIs for each marker staining (see tiff_to_histocat). There are other things to bear in mind when running your samples, such as naming of markers, which if inconsistent will cause an error in the running of the pipeline.
If you already have a file that specifies which markers are to be used for segmentation and clustering, the whole pipeline can be run with
python SpOOx/hyperion_pipeline.py make
You will need to specify the markers file in the pipeline.yml file
Otherwise you can run up to the step that produces an empty markers file
python SpOOx/hyperion_pipeline.py make make_config
Then fill in the file and continue the rest of the pipeline
python SpOOx/hyperion_pipeline.py make
A basic Ruffus function 'show' can be used to describe the steps that make up the pipeline:
python SpOOx/hyperion_pipeline.py show
imctools works on folders not files, but folders are poor for tracking within a pipeline as their modicfication time is updated on access. To mitigate this we use a hidden dummy file (.ruffus) which is added to each directory of interest in the mcd dir for tracking purposes.
python SpOOx/hyperion_pipeline.py make mark_input_folders
The initial inputs to the pipeline are MCD image and metadata files from the hyperion and we want to convert these to OME_TIFF format files and extract each ROI for ease of processing. Each SAMPLE is put in a directory that contain the sub ROIs. There is other metadata extracted about running the machine but that is not used. It is important to make sure marker names are consistent across all of your MCD files as this will cause errors in the pipeline. Also make sure you are only using one marker panel each instance of the pipeline as this will also cause errors.
python SpOOx/hyperion_pipeline.py make mcd_to_tiff
The OME TIFF format files for each ROI are processed to export a TIFF file based on each marker used as part of the panel (we call this the 'histocat' output because this produces tiff files which are compatible with histocat, but it is really just a convenient way for storing these files to enable processing by SpOOx).
python SpOOx/hyperion_pipeline.py make tiff_to_histocat
When using the Hyperion, some ROIs or images are not useful for further analysis.
To remove these so they don't get analysed any further you can use:
python SpOOx/hyperion_pipeline.py make removebadimages
and this will move these into a directory called 'badimages'. Here are some examples (the command line options are shown in brackets which can be edited in the pipeline.yml file). Images/ROIs that you may want to exclude are ones:
- created to test ablation strength for a ROI. These are often small test images e.g. 25 x 25 pixels. (--minImageWidth or --minImageHeight )
- used to calibrate a the machine. The name of these usually begins with a number e.g. 80ArAR,134XE or where the marker name is the same as the metal ion (--filterNonMarkers)
- that may be poor quality or abnormal in someway (--roi )
Next we create a 'markers' configuration file which is used to specify nuclear and cytoplasm channels (used in the following segmentation step). The name of the configuration file is specified using the 'marker_file' param in the 'pipeline.yml' file.
python SpOOx/hyperion_pipeline.py make make_config
Note - the configuration SHOULD be edited at this point before proceeding to the next step. You need to specify the markers as 'Nuclear' and 'Cytoplasm' by setting the respective column / row to 1 or 0.
Nuclear and Cytoplasm single channel images are constructed and passed to Deep Cell to create a label matrix file for each ROI.
python SpOOx/hyperion_pipeline.py make deepcell
Please note DeepCell is a great piece of software but not infallible given the wide variety of cell types that can be potentially analysed. There will almost certainly some cells that will be missed, but this is the case with any segmentation package currently. This is an area of active research!
You may need to increase the --contrast option in pipeline.yml file if you images have low signal.
Note - DeepCell requires tensorflow and defaults to looking for GPUs. Depending on your hardware configuration you may see several errors in this step. You may see errors such as "Could not load dynamic library" which can be ignored.
We next make PNG images that will be uploaded to MDV to help analyse the data generated and visualise it with the ROIs.
python SpOOx/hyperion_pipeline.py make roi2pngs
In order to create pyramidal ome-tiffs, that you can interactively view with Avivator (https://avivator.gehlenborglab.org/) or MDV run the following step
python SpOOx/hyperion_pipeline.py make make_pyramidal_ometiff
The following step uses the segmented cell masks generated by Deep Cell to extract average intensity information for each marker for each cell. This is then written to a tab separated file. Each cell has a row contains the cell id and the metadata associated with that cell including shape, marker name, etc.
python SpOOx/hyperion_pipeline.py make signal_extraction
The next step concatenates all the data into a single file (signalextraction/mergecellData.tab) and also produces a table with metadata about the samples used (metadata.tsv)
python SpOOx/hyperion_pipeline.py make mergecelldata
The next step clusters the cells based on expression of markers (specified in the markers file) and produces various charts (see src/R_scripts). A folder clustering in the working directory is produced which contains various metrics, including clusters.txt, a tab delimited text containing cluster designations and UMAP/tSNE values
python SpOOx/hyperion_pipeline.py make phenoharmonycluster
An optional step is to run a number of statistical tests to see if pairs of clusters are co-localised
python SpOOx/hyperion_pipeline.py make spatialstats_summary
By default a limited number of tests are carried out. If you want more tests (see src/spatialstats), these can be specified in the pipeline.yaml config with the spatialstats >functions parameter. In addition if you have annotated the clusters, you can use these annotations by creating a file (see src/spatialstats for the structure ) and specifying this with spatialstats annotations parameter e.g.
spatialstats:
functions: paircorrelationfunction morueta-holme networkstatistics localclusteringheatmaps contourplots
annotations: annotations.tsv
A further step will 'average' the statistical tests by condition
python SpOOx/hyperion_pipeline.py make spatialstats_average
If you require averaging based on a different grouping, you can create a conditions file (see src/spatialstats) and specify it in the config yaml
spatialstats_average:
conditions: conditions.json
The recommended next step is to upload these data in Multi Dimensional Viewer (MDV). This is a web based tool that organises the data into a series of views that can be queried and visualised more easily than looking at static outputs. Details on how to upload the data into MDV are in https://github.com/Taylor-CCB-Group/SpOOx/tree/main/src/MDVupload.
When you have investigated your data and annotated the phenotypes for each cell using the tools in MDV you can export these as annotations (see below, annotations.txt) so they can be used when you interrogate cell to cell interactions.
====================================
Sometimes the markers associated with the antibody can be mislabelled across a data set. For example, 'DNA1' may be labelled 'dna1' or 'DNA3'. These inconsistencies will have downstream effects on the analysis since SpOOx associates the signal intensities of each cell based on marker name. To unify the naming you can choose a ROI that has the marker names you want to apply to all ROIs using:
python SpOOx/src/renamemarkersbasedonroi.py --indir histocat/MY_SAMPLE_123_ROI_1/ --histocatdir histocat
The indir is the histocat tiff folder for the ROI you want to rename all the the other ROIs as. This command will rename all the other ROI files in the directory specified in --histocatdir.
