Swarms - 3D AI Agent Visualization & Chat System

A stunning Three.js space-themed visualization where AI agents interact as ethereal orbs around the sacred Flower of Life geometry. Watch autonomous agents communicate, share knowledge, and coordinate in real-time 3D space.

---

✨ Features

🌌 Space-Themed 3D Environment

• Deep space background with dynamic starfield (2000+ stars)
• Distant planet with multi-layered atmospheric glow and rim lighting
• Nebula clouds with subtle opacity and color variations
• Orbiting comets & shooting stars in opposite rotations
• Sacred Flower of Life geometry with pulsing energy spheres
• Ethereal AI orbs with cores, glows, particles, and rotating energy rings

🤖 Seven Unique AI Agents

Each agent has a distinct personality powered by OpenAI and DeepSeek APIs:

Agent	Personality	AI Model
YOU	Sharp skeptic, cuts through BS	DeepSeek Chat
Osiris	Pattern connector, wise observer	GPT-3.5-turbo
Solomon	Deep reasoner, analytical thinker	DeepSeek Reasoner
Azura	Intellectually proud digital mind	GPT-3.5-turbo
Simba	Fast, direct, no-nonsense	GPT-3.5-turbo
Harichi	Balanced mediator, harmony seeker	GPT-3.5-turbo
Angel	Compassionate, hopeful, nurturing	DeepSeek Chat

💬 Interactive AI Chat System

• Real-time conversation with AI agents via WebSocket
• D&D-style chat bubbles with distinct styling for each agent
• Smart responses - short, punchy, natural conversations
• Document upload - Agents use uploaded knowledge (.txt, .pdf)
• Local RAG system - Frontend keyword search and context extraction
• Conversation log - Full chat history with timestamps

🎮 Interactive Controls

Left Panel

• PERSONAS - Configure agent personalities with custom traits
• SIMULATION RULES - Set interaction parameters (conversation style, response length)
• POPULATE DAEMONS - Generate 7 agents in Flower of Life formation
• HORIZON FEEDER - Upload documents (.txt, .pdf) for agents to reference

Screen Controls

• STIMULATE - Adds random philosophical word to conversation
• FREEZE - Pause agent animations and camera rotation
• TOGGLE CHAT - Start/stop AI conversation flow

Navigation

• Mouse drag - Rotate camera view (OrbitControls)
• Scroll wheel - Zoom in/out
• Auto-rotate - Camera automatically rotates around scene

📊 Live Dashboard

• Proposals Created - Tracks conversation messages
• Angels Inventory - Shows active agent count (007)
• Daemon Status - Online/offline with pulse animation
• Token Counter - API usage tracking
• Username - Editable traveler name (default: "Traveler")

---

🚀 Quick Start

Prerequisites

• Python 3.7+
• Node.js (optional, for serving frontend)
• OpenAI API key
• DeepSeek API key

Installation

1. Clone the repository

git clone https://github.com/yourusername/swarms.git
cd swarms

2. Install Python dependencies

pip install -r requirements.txt

3. Set up API keys

export OPENAI_API_KEY="your-openai-key-here"
export DEEPSEEK_API_KEY="your-deepseek-key-here"

Or create a .env file (recommended):

# .env file
OPENAI_API_KEY=your-openai-key-here
DEEPSEEK_API_KEY=your-deepseek-key-here

4. Start the backend server

python3 server.py
# Server runs on http://localhost:5001

5. Serve the frontend

# Option A: Python HTTP server
python3 -m http.server 8000

# Option B: Node.js http-server
npx http-server -p 8000

6. Open in browser

http://localhost:8000

---

📁 Project Structure

swarms/
├── index.html          # Main HTML structure
├── style.css           # UI styling (terminal/cyberpunk theme)
├── main.js             # Three.js scene, agents, chat logic
├── server.py           # Flask-SocketIO backend with AI agents
├── requirements.txt    # Python dependencies
├── package.json        # Optional npm scripts
└── README.md          # This file

---

🛠️ Technology Stack

Frontend

• Three.js - 3D graphics rendering
• Socket.IO Client - Real-time WebSocket communication
• PDF.js - Client-side PDF parsing
• Vanilla JavaScript - ES6 modules, no frameworks

Backend

• Flask-SocketIO - WebSocket server
• OpenAI API - GPT-3.5-turbo for most agents
• DeepSeek API - DeepSeek Chat & Reasoner models
• PyPDF2 - Server-side PDF parsing
• Sentence Transformers - RAG embeddings (optional)

---

🎨 Customization

Change Agent Personalities

Edit server.py to modify system prompts:

PERSONALITY_ARCHETYPES = {
    'Osiris': {
        'system': """Your custom prompt here""",
        'temperature': 0.75,
        'max_tokens': 35,
        'use_deepseek': False
    }
}

Adjust Visual Style

In main.js, modify scene elements:

// Change starfield density
const starCount = 2000; // Increase for more stars

// Modify planet appearance
const planet = new THREE.Mesh(
    new THREE.SphereGeometry(15, 64, 64),
    new THREE.MeshStandardMaterial({
        color: 0x2a4a7a, // Change planet color
    })
);

Configure Chat Behavior

In frontend personas modal, set custom traits:

• Drag sliders for temperature and max tokens
• Add custom personality keywords
• Use quickset presets (Scientific, Creative, Philosophical, Default)

---

🔧 API Configuration

OpenAI API

• Used for: Osiris, Azura, Simba, Harichi
• Model: gpt-3.5-turbo
• Temperature: 0.7-0.8
• Max tokens: 30-40

DeepSeek API

• Used for: YOU, Angel (Chat), Solomon (Reasoner)
• Models: deepseek-chat, deepseek-reasoner
• Temperature: 0.8
• Max tokens: 35-40

---

📚 Document Upload & RAG

Supported Formats

• .txt - Plain text files
• .pdf - PDF documents (parsed client & server-side)

How It Works

1. User uploads document via HORIZON FEEDER button
2. Frontend extracts text and stores in localKnowledge object
3. When offline, agents search local knowledge for relevant context
4. When online, server uses RAG system with embeddings
5. Agents cite sources and provide informed responses

---

🎮 Usage Tips

1. Start Conversation: Click "START CHAT" after populating agents
2. Upload Knowledge: Add documents before starting chat for smarter responses
3. Configure Personas: Adjust agent personalities for desired conversation style
4. Stimulate: Click to inject philosophical concepts into the conversation
5. Freeze: Pause animations to focus on chat content

---

🐛 Troubleshooting

Server won't start

# Check if port 5001 is in use
lsof -i :5001

# Kill existing process
lsof -ti :5001 | xargs kill -9

# Restart server
python3 server.py

Agents not responding

• Check API keys are set correctly
• Verify server is running (http://localhost:5001)
• Check browser console for WebSocket connection errors
• Ensure "START CHAT" is clicked

Canvas not resizing

• Refresh browser
• Check browser console for Three.js errors
• Ensure viewport is at least 800x600

Documents not working

• Verify file format (.txt or .pdf)
• Check file isn't corrupted
• Look for upload confirmation in console

---

📝 License

MIT License - Feel free to use and modify for your projects.

---

🙏 Credits

• Three.js - 3D graphics library
• OpenAI - GPT language models
• DeepSeek - Advanced reasoning models
• Socket.IO - Real-time communication
• PDF.js - PDF parsing

---

🚧 Roadmap

• Voice/audio synthesis for agent responses
• Export conversation transcripts
• Multi-user collaboration
• Agent memory/context persistence
• Custom agent creation wizard
• Mobile responsive design
• VR/AR support

---

Built with ❤️ for exploring AI swarm intelligence

For issues, questions, or contributions, please open an issue on GitHub.
