Get started in under 5 minutes, or your money back! 😉

This repo contains a minimal example to get you started using LittleHorse in Go. LittleHorse is a high-performance orchestration engine which lets you build workflow-driven microservice applications with ease.

You can run this example in two ways:

1. Using a local deployment of a LittleHorse Server (instructions below, requires one docker command).
2. Using a LittleHorse Server deployed in a cloud sandbox (to get one, contact info@littlehorse.io).

In this example, we will run a classic "Greeting" workflow as a quickstart. The workflow takes in one input variable (input-name), and calls a greet Task Function with the specified input-name as input.

Prerequisites

Your system needs:

• go
• [Optional] brew (to install lhctl). This has been tested on Linux and Mac.
• docker (to run the LH Server) or access to a LH Cloud Sandbox.

Setup Go

To add the LittleHorse Go Client to your project, you can use the following command:

go get github.com/littlehorse-enterprises/littlehorse@v0.11.2

LittleHorse CLI

Install the LittleHorse CLI:

brew install littlehorse-enterprises/lh/lhctl

Local LH Server Setup

If you have obtained a private LH Cloud Sandbox, you can skip this step and just follow the configuration instructions you received from the LittleHorse Team (remember to set your environment variables!).

To run a LittleHorse Server locally in one command, you can run:

docker run --name littlehorse -d -p 2023:2023 -p 8080:8080 ghcr.io/littlehorse-enterprises/littlehorse/lh-standalone:0.11.2

Using the local LittleHorse Server takes about 15-25 seconds to start up, but it does not require any further configuration. Please note that the lh-standalone docker image requires at least 1.5GB of memory to function properly. This is because it runs kafka, the LH Server, and the LH Dashboard (2 JVM's and a NextJS app) all in one container.

Verifying Setup

At this point, whether you are using a local Docker deployment or a private LH Cloud Sandbox, you should be able to contact the LH Server:

->lhctl version
lhctl version: 0.11.2 (Git SHA homebrew)
Server version: 0.11.2

You should also be able to see the dashboard at https://localhost:8080. It should be empty, but we will put some data in there soon when we run the workflow!

If you can't get the above to work, please let us know on our Community Slack Workspace. We'll be happy to help.

Running the Example

Without further ado, let's run the example start-to-finish.

Register Workflow

First, we run src/register, which does two things:

1. Registers a TaskDef named greet with LittleHorse.
2. Registers a WfSpec named quickstart with LittleHorse.

A WfSpec specifies a process which can be orchestrated by LittleHorse. A TaskDef tells LittleHorse about a specification of a task that can be executed as a step in a WfSpec.

go run ./src/register/

You can inspect your WfSpec with lhctl as follows. It's ok if the response doesn't make sense, we have a UI coming really soon which visualizes it for you!

lhctl get wfSpec quickstart

Now, go to your dashboard in your browser (http://localhost:8080) and refresh the page. Click on the quickstart WfSpec. You should see something that looks like a flow-chart. That is your Workflow Specification!

Run Workflow

Now, let's run our first WfRun! Use lhctl to run an instance of our WfSpec.

# Run the 'quickstart' WfSpec, and set 'input-name' = "obi-wan"
lhctl run quickstart input-name obi-wan

The response prints the initial status of the WfRun. Pull out the id and copy it!

Let's look at our WfRun once again:

lhctl get wfRun <wf_run_id>

If you would like to see it on the dashboard, refresh the WfSpec page and scroll down. You should see your ID under the RUNNING column. Please double-click on your WfRun id, and it will take you to the WfRun page.

Note that the status is RUNNING! Why hasn't it completed? That's because we haven't yet started a worker which executes the greet tasks. Want to verify that? Let's search for all tasks in the queue which haven't been executed yet. You should see an entry whose wfRunId matches the Id from above:

lhctl search taskRun --taskDefName greet --status TASK_SCHEDULED

You can also see the TaskRun node on the workflow. It's highlighted, meaning that it's already running! If you click on it, you can see that it is in the TASK_SCHEDULED status.

Run Task Worker

Now let's start our worker, so that our blocked WfRun can finish:

go run ./src/worker

Once the worker starts up, please open another terminal and inspect our WfRun again:

lhctl get wfRun <wf_run_id>

Voila! It's completed. You can also verify that the Task Queue is empty now that the Task Worker executed all of the tasks:

lhctl search taskRun --taskDefName greet --status TASK_SCHEDULED

Please refresh the dashboard, and you can see the WfRun has been completed!

Advanced Topics

You have now passed the requirements to reach the level of Jedi Youngling. Want to become a Padawan, or even a Knight? Then keep reading!

Here are some cool commands which scratch the surface of observability offered to you by LittleHorse. Note that we are almost done with a UI which will let you do this via click-ops rather than bash-ops.

Also, note that everything we are doing here can be done programmatically via our SDK's, but it's easier to demonstrate with lhctl.

Inspect the TaskRun

Let's find the completed TaskRun:

lhctl search taskRun --taskDefName greet --status TASK_SUCCESS

Take the output from above, and inspect it! Notice that you can see the input variables and also the output, which is a greeting string.

lhctl get taskRun <wf_run_id> <task_guid>

Search for Someone's Workflow

Remember we passed an input-name variable to our workflow? If you look in register_workflow.py, specifically the get_workflow() function, you can see that we created an Index on the variable. This means we can search for variables by their value!

lhctl search variable --varType STR --wfSpecName quickstart --name input-name --value obi-wan

And the following should return an empty list (unless, of course, you do lhctl run quickstart input-name asdfasdf)

lhctl search variable --varType STR --wfSpecName quickstart --name input-name --value asdfasdf

NodeRuns and TaskRuns

Let's look at our WfRun:

-> lhctl get wfRun <wfRunId>
{
  "id": "4a139cd6326944d8a2f2021385a259e0",
  "wfSpecName": "quickstart",
  "wfSpecVersion": 0,
  "status": "COMPLETED",
  "startTime": "2023-10-15T04:56:26.292Z",
  "endTime": "2023-10-15T04:56:57.158Z",
  "threadRuns": [
    {
      "number": 0,
      "status": "COMPLETED",
      "threadSpecName": "entrypoint",
      "startTime": "2023-10-15T04:56:26.350Z",
      "endTime": "2023-10-15T04:56:57.154Z",
      "childThreadIds": [],
      "haltReasons": [],
      "currentNodePosition": 2,
      "handledFailedChildren": [],
      "type": "ENTRYPOINT"
    }
  ],
  "pendingInterrupts": [],
  "pendingFailures": []
}

There are a few things to note:

• The status is COMPLETED
• There is one ThreadRun. That makes sense, since we didn't add multi-threading to the WfRun.
• The currentNodePosition is 2.

What is a NodeRun? A NodeRun is a step in a ThreadRun. Our workflow's main ThreadRun has three steps:

1. The ENTRYPOINT node
2. The TASK node to execute the greet task
3. The EXIT node, which wraps things up.

Let's see all of our nodes via:

lhctl list nodeRun <wfRunId>

Note that the second nodeRun has a task field, points to the TaskRun we saw earlier. You can find it via:

lhctl get taskRun <wfRunId> <taskGuid>

Debugging Errors

What happens if a Task Run fails? Edit worker.go and make the greeting() function throw an error of choice (maybe errors.New("asdf") or something like that). Then, restart the worker via go run ./src/worker/.

Run another workflow:

lhctl run quickstart input-name anakin

Then, lhctl get wfRun <wfRunId> should show that the workflow failed. It should also show that currentNodePosition for ThreadRun 0 is 1. Let's inspect the NodeRun:

lhctl get nodeRun <wfRunId> 0 1

It's a TaskRun! Let's see what happened:

lhctl get taskRun <wfRunId> <taskGuid>

As you can see, you can get the stack trace through the LittleHorse API.

You can also find the TaskRun by searching for failed tasks. Remember that all of this will be presented in a super-cool UI once we have it finished.

lhctl search taskRun --taskDefName greet --status TASK_FAILED

# or search for workflows by their status
lhctl search wfRun --wfSpecName quickstart --status ERROR
lhctl search wfRun --wfSpecName quickstart --status COMPLETED

If you want to handle such failures in your workflow, check our exception handling documentation.

Next Steps

If you've made it this far, then it's time you become a full-fledged LittleHorse Knight!

Want to do more cool stuff with LittleHorse and Go? You can find more Go examples here. This example only shows rudimentary features like tasks and variables. Some additional features not covered in this quickstart include:

• Conditionals
• Loops
• External Events (webhooks/signals etc)
• Interrupts
• User Tasks
• Multi-Threaded Workflows
• Workflow Exception Handling

We also have quickstarts in Java and Python. Support for .NET is coming soon.

Our extensive documentation explains LittleHorse concepts in detail and shows you how take full advantage of our system.

Our LittleHorse Server is free for production use under the SSPL license. You can find our official docker image at the AWS ECR Public Gallery. If you would like enterprise support, or a managed service (either in the cloud or on-prem), contact info@littlehorse.io.

Happy riding!
