🚦 Traffic Sign Classification Using LeNet CNN

A deep learning project implementing LeNet-5 architecture to classify traffic signs from the German Traffic Sign Recognition Benchmark (GTSRB) dataset with 99%+ validation accuracy.

📌 Course Project - Deep Learning & Computer Vision
📁 Repository: ML-project1-Traffic-Sign-Classification

---

📌 Project Highlights

• 🖼️ 43 classes of traffic signs classified
• 🧠 Implemented LeNet-5 CNN architecture from scratch
• 🔍 Achieved 99.2% validation accuracy
• 📊 Comprehensive model performance analysis
• ⚡ Data augmentation techniques applied

---

📂 Dataset Overview

Dataset: German Traffic Sign Recognition Benchmark (GTSRB)

Category	Details
Total Classes	43
Training Images	34,799
Validation Images	4,410
Test Images	12,630
Image Size	32×32 pixels (RGB)

---

🔧 Technical Stack

🧠 Deep Learning

📊 Visualization

🛠️ Utilities

---

🚀 Model Architecture (LeNet-5)

graph LR
    A[Input 32x32x3] --> B[Conv2D 6@28x28]
    B --> C[AvgPool 6@14x14]
    C --> D[Conv2D 16@10x10]
    D --> E[AvgPool 16@5x5]
    E --> F[Flatten 400]
    F --> G[Dense 120]
    G --> H[Dense 84]
    H --> I[Output 43]

Loading

Hyperparameters

• Optimizer: Adam (lr=0.001)
• Loss: Categorical Crossentropy
• Epochs: 50
• Batch Size: 64
• Augmentation: Rotation (±15°), Zoom (±10%)

📊 Performance Metrics

Metric	Training	Validation
Accuracy	99.8%	99.2%
Precision	99.7%	99.1%
Recall	99.6%	99.0%
F1-Score	99.6%	99.0%

Confusion Matrix:

🛠️ Installation & Usage

# Clone repository
git clone https://github.com/mdzaheerjk/ML-project1-Traffic-Sign-Classification.git
cd ML-project1-Traffic-Sign-Classification

Install dependencies

pip install -r requirements.txt

Launch Jupyter Notebook

jupyter notebook "Project 5 - Traffic Sign Classification Using LeNet Network in Keras.ipynb"

📂 Project Structure

ML-project1-Traffic-Sign-Classification/
├── Project/
│   ├── traffic-signs-data/       # Dataset samples
│   ├── Project 5 - Traffic Sign Classification Using LeNet Network in Keras.ipynb
│   └── Project 5 - Traffic Sign Classification Using LeNet.pptx
├── .gitattributes
├── LICENSE
└── README.md

✍️ Author

Mohammed Zaheeruddin

🎓 First-Year B.Tech Student | AI/ML Enthusiast

🏫 Shetty Institute of Technology, Gulbarga

📧 info.zaheerjk@gmail.com

📜 License

This project is licensed under the MIT License - see the LICENSE file for details.
