ONVIF Products Directory

This project is a comprehensive ONVIF data aggregation and management suite, designed to help developers explore, analyze, and process ONVIF-compliant product information from hundreds of manufacturers worldwide. It provides a unified structure for device, client, and company data, making it easier to perform research, build integrations, and generate statistics for ONVIF ecosystem analysis.

This directory contains ONVIF product data imported and organized by company. Data is sourced from JSON and ONVIF API (https://www.onvif.org), then stored in a structured folder hierarchy.

Directory Structures

Important

The folders companies/, databases/json/, and databases/mysql/ are not included in the repository. Developers must run the provided scripts to generate these directories and their contents locally.

products/
├── README.md
├── companies/
│   └── [Company Name]/
│       ├── [company].json
│       └── [product_type]/
│           └── [Device Name]/
│               ├── [device].json
│               └── [device_onvif_feature_list].xml
├── databases/
│   ├── json/
│   ├── mysql/
│   ├── sqlite/
│   └── onvif_data.json
├── device-test/
├── scripts/

Databases

Below is the structure of the databases directory, including the contents and their descriptions:

Folder	Files	Description
json/	companies.json products.json	JSON exports for all company and product data (arrays preserved)
mysql/	companies.sql products.sql	MySQL dump files with CREATE TABLE and INSERT statements
sqlite/	companies.db products.db	SQLite databases for company and product data
(root)	onvif_data.json	Main JSON file containing all ONVIF meta data

Device Testing

The device-test/ directory contains scripts, data, and documentation related to ONVIF device testing. This folder is used to store test results, test configurations, and references for validating ONVIF compatibility across various products. Users can add test results, logs, or custom test scripts as needed to support device verification and analysis processes.

Scripts

The scripts directory provides a practical workflow for ONVIF data management, from initial data retrieval to final reporting:

1. import_products_to_json.py – Fetches and saves ONVIF product and company data from JSON sources and the ONVIF API. Data is stored in a Windows-safe folder structure and normalized for database import.

2. import_products_to_db.py – Imports the JSON data generated by the previous script into SQLite databases (.db), and also exports to MySQL (.sql) and global JSON formats. This script ensures data type conversion and Windows file/folder name compatibility.

3. update_readme.py – Analyzes the database contents and automatically updates the README with the latest product statistics and top company rankings. Documentation is always synchronized with the actual data.

4. shorten_filenames.py – Scans all files in products/companies and shortens filenames (not folders) so that the total path does not exceed 240 characters. Filenames are trimmed from the end, with the extension preserved, to prevent Windows/Git errors caused by long paths.

Main workflow:

# 1. Fetch and normalize ONVIF data
python import_products_to_json.py

# 2. Import data into the database
python import_products_to_db.py

# 3. Update documentation and statistics
python update_readme.py

# 4. (Optional) Shorten filenames to ensure safe paths
python shorten_filenames.py

Products Statistics

Note

Last updated on : September 17, 2025

This section summarizes the total number of ONVIF products, devices, and clients available in the database. These statistics provide an overview of the data coverage and diversity.

Total Products	Devices	Clients	Other
33493	30040	3448	5
All ONVIF-compliant products	Physical devices (cameras, encoders, etc.)	Clients (VMS, NVR, apps)	Other types (tools, add-ons)

Top 20 company based on total products

Note

Last updated on : September 17, 2025

Logo	Company	Country	Website	Device	Client	Total
	Hangzhou Hikvision Digital Technology Co., Ltd.	China	http://www.hikvision.com/	6756	1674	8430
	Dahua Technology	China	http://www.dahuasecurity.com	3121	12	3133
	Zhejiang Uniview Technologies Co., Ltd.	China	http://www.uniview.com	1548	263	1811
	Shenzhen TVT Digital Technology Co.,Ltd	China	http://www.tvt.net.cn	825	1	826
	Longse Technology Limited	China	http://www.longse.com	761	33	794
	Axis Communications AB	Sweden	https://www.axis.com	734	0	734
	Norden Communication UK Ltd	United Kingdom	http://www.nordencommunication.com	643	13	656
	Tiandy Technologies Co, Ltd	China	http://en.tiandy.com/	552	87	639
	Hanwha Vision Co., Ltd	Korea, Republic of	https://www.hanwhavision.com/en	540	94	634
	Honeywell International Inc	United States	https://www.security.honeywell.com/	473	106	579
	i-Pro Co., Ltd.	Japan	https://i-pro.com/	553	23	577
	IDIS Co., Ltd	South Korea	http://www.idisglobal.com/	450	97	547
	Aditya Infotech Ltd	India	http://www.cpplusworld.com	477	42	519
	ACTi Corporation	Taiwan, Province of China	http://www.acti.com	489	21	510
	VIVOTEK INC.	Taiwan, Province of China	http://www.vivotek.com	456	19	475
	Merit LILIN Ent. Co., Ltd.	Taiwan	http://www.meritlilin.com	373	73	446
	GeoVision Inc.	Taiwan	http://www.geovision.com.tw	372	4	376
	Carrier Fire & Security BV	Poland	www.firesecurityproducts.com	337	0	337
	Speco Technologies	United States	http://www.specotech.com	301	18	319
	Provision-ISR	Hong Kong	http://www.provision-isr.com	311	0	311

Legal Notice

This project and its data are provided for research and educational purposes only. All ONVIF product names, company names, logos, and trademarks are property of their respective owners. The ONVIF data is aggregated from public sources and the ONVIF API, and is not guaranteed to be complete or error-free. Use of this data is at your own risk. The maintainers of this repository are not affiliated with ONVIF or any listed company. For official information, please refer to https://www.onvif.org.
